13

selected level. The period of time the cooking

area will remain at maximum power depends on

the nal cooking level that is set. See table:

Lev. Power Time

1 48 seconds

2 144 seconds

3 230 seconds

4 312 seconds

5 408 seconds

6 120 seconds

7 168 seconds

8 216 seconds

9 not available

P not available

To activate, with a pan on the hob and selected

cooking area, press and hold for 3 seconds on the

selected value (from 1 to 8) on the power bar. The

Display for the corresponding area shows “ A “ .

It is possible to increase the cooking level, but if it

is decreased the function is deactivated.

It can also be deactivated by pressing and hol-

ding for 3 seconds the button for the cooking area

in question.

MODEL

GALILEO HE BK

GLASS NG A83

Max Total Power 7,620 kW

Error codes

Error code Description Possible cause of error Remedy

ER 03 and

continuous tone

Continuous sensor

activation; TC turn o󰀨

after 10 sec

Water or cookware on the glass

over the touch control sensors

Clean the control surface,

remove objects on the

sensors.

ER20 Flash memory – TC error μC- defective Replace TC

ER22 Button evaluation

defective, UI shuts o󰀨

after 3.5-7.5 sec

Short or open circuit in the area

of the button sensoric

Replace TC

ER31 Incorrect conguration

data or deviation between

generator and TC

New conguration of the

induction generator required

New conguration (Service

menu)

ER36 NTC value defective on

TC; UI turns o󰀨

Short or open circuit of NTC Replace TC

ER47 Communication error

between TC and induction

No or erroneous LIN

communication! (Slave does not

answer to request of master)

Connection cable not correctly

plugged in or defective.

U400 Continuous tone Power

supply on inlet to high

Incorrect connection of the

cooktop

Correct power supply

connection

E/2 Excess temperature of

the induction element

Overload of cooktop or empty

boiled cookware

Let system cool down.

E/A Error on the power board Component failure Replace power board

E/6 Error on power board No power supply or error on

power board

1. check wiring

2. check lter board

3. replace power board

E/8 Incorrect fan speed Error on fan left or right Air exhaust blocked, e.g. by

paper Replace Defective fan

E/9 Defective temperature

sensor on inductor

Replace inductor Replace

power board
