TLI Pro 201 • On-screen Menus 21
System Info (see figure 20 on page 20) — This panel allows you to add the TLI Pro 201 to a system by pairing it
with a primary controller.
1. Click EDIT.
The System ID popup opens.
System ID
Select field to edit
Primary Controller Address
System ID
SAVE CANCEL
0987654321
q we rtyuiop
a s dfgh jkl
-zx c v bnm .
Figure 21. System ID Popup
2. Click inside the Primary Controller Address text box and use the keyboard to enter the IP address of the
control processor with which the TLI Pro 201 is to be paired.
3. Click inside the System ID text box and use the keyboard to enter the System ID. This is a number generated
by Global Configurator Plus and Professional and assigned to the controller when the project is set up. For
more information, see the Global Configurator Plus and Professional Help File.
4. Click SAVE.
Storage Panel (see figure 20) is read only.
Menu PIN (see figure 20) — To prevent unauthorized access to the setup menu, users can set a 4-digit PIN. Each
digit can have any value from 0-9. The PIN EDIT options allow you to enable, disable, or change the setup menu
PIN.
To disable the PIN, set the Menu Pin switch to Off.
1. To enable or change the PIN, set the Menu Pin switch to On.
2. If there is an existing PIN, you can press EDIT.
The Enter New PIN dialog opens:
Enter New PIN
123
65
9
8
4
7
0
SUBMIT
Figure 22. Enter New PIN dialog box
3. Enter a four-digit PIN. The numbers entered remain hidden.
4. Press SUBMIT.
When the PIN has been entered correctly, the title bar changes to Confirm New Menu PIN.
5. Enter the PIN a second time and press SUBMIT. When the PIN entered on the second occasion matches the
PIN entered on the first occasion, the new PIN is set and the dialog closes.
