TLI Pro 201 • On-screen Menus 12
Network
Verify with your network administrator whether the IP address for the TLI is assigned by Dynamic Host
Configuration Protocol (DHCP) or set manually. If they are set manually, you need to obtain an IP Address, a
Subnet Mask, a Gateway Address, and a Domain Name Server (DNS) IP address from the network administrator.
Touchpanel Setup
EXIT
STATUS
NETWORK
OUTPUT
INPUT
AUDIO
PROJECT INFORMATION
ADVANCED
Network
DHCP
SAVE CANCEL
IP Address
Hostname
Subnet Mask
255.255.255.0
192.168.254.251
TLI-Pro-201-xx-xx-xx
Gateway
DNS Primary
127.0.0.1
0.0.0.0
MAC Addres
00-05-A6-xx-xx-xx
Domain Name
Figure 7. Network Screen
1. If the IP address is to be assigned by DHCP, toggle the switch to On. If the IP address is to be assigned
manually, toggle the switch to Off.
• When DHCP is off, the Host Name cannot be edited. All addresses can be edited (see figure 9 on
page 13).
• When DHCP is on, the Host Name can be edited. The addresses cannot be edited because they are set
by the DHCP server.
2. If DHCP is on, click the right arrow (>) next to the Host Name. The Host Name dialog box opens:
Hostname
TLI-Pro-201-xx-xx-xx
eqw rtyu iop
asdfgh jkl
zxcvbnm-
SUBMIT123
Figure 8. Host Name Dialog Box
3. Use the keypad to enter a new name, which appears in the Host Name text box.
