Installation
Overview
1. Before starting, download and install the latest versions of the following software:
GUI Designer — for designing layouts for Extron TouchLink Pro touchpanels and
third party touch interfaces.
Global Configurator Plus and Professional — for setting up and configuring the
control processor and touchpanel.
Toolbelt — provides device discovery, device information, firmware updates,
and configuration of network settings, system utilities, and user management for
TouchLink Pro devices.
Global Scripter — Provides an integrated development environment for Extron
control systems programming.
See Configuration Software on page 23.
2. Obtain the following network information from your network administrator:
DHCP setting (On or Off). If the DHCP setting is Off, you also need:
TLI Pro 101 IP address
Subnet mask
Gateway IP address
User name — by default these are either admin or user.
Passwords — the factory configured passwords for all accounts on this device
have been set to the device serial number. Passwords can be changed during
configuration. They are case sensitive.
NOTE: If the device is reset to default settings, the passwords are reset to the
default password, which is extron (for either admin or user).
MAC address — make a note of the TLI Pro 101 MAC address.
3. Mount the units. Stand the TLI Pro 101 on a convenient surface, mount it in a standard
rack, or use an under-table mounting kit (see Mounting on page 29). To mount the
third-party touchpanel follow the instructions provided by the manufacturer.
4. Connect cables to the TLI Pro 101 (see TLI Pro 101 Rear Panel Features and
Connections on page 5).
Connect the HDMI output from the TLI Pro 101 (figure 2,
C
on page 5) to the
third-party touchpanel.
Connect the USB port from the TLI Pro 101 (
D
) to the third-party touchpanel.
NOTE: The USB connection passes information to the TLI Pro 101 about where on
the screen the touchpanel was pressed. To use a normal monitor instead of a
touchscreen, connect a mouse to the TLI Pro 101 USB connection. Use the mouse
to click on screen icons.
TLIPro101 • Installation Overview 3
