Network Button Panels • Hardware Features and Installation — NBP 1200C 41
Step 10: Set up the NBP 1200C for Network Communication
1. Connect the NBP button panel and the PC to be used for
setup to the same Ethernet subnetwork.
2. Start Toolbelt and use it to set DHCP on or to set the
IP address, subnet, gateway IP address, DHCP status,
and related settings. Network setup is essential prior to
conguration.
Use the flowchart at right as a guide to setting up the unit
for network use.
NOTES:
• If using a host name instead of an IP address
the user must enter a qualified host name
(
Username.HostName.Domain
)
.
For example:
somename.somedomain.com
.
• If using 802.1X security, see the Extron 802.1X
Technology Reference Guide and the Toolbelt
Help file for additional details on system setup.
Step 11: Configure the System
Use Global Congurator (GC Plus or GC Professional) to congure the control processor. Alternatively, use
the ControlScript deployment utility to program the control processor. That conguration sets the control and
monitoring behavior for all the AV devices and control accessories (such as the NBP button panels) in the system.
An outline of the main conguration and programming steps is included in the user guide for the control processor.
When conguration or programming is completed, save the project or program script, then build and upload the
system conguration to the control processor.
Step 12: Test and Troubleshoot
1. Test the system (see the user guide for the control processor for an outline of the system testing and
troubleshooting procedure).
2. Make adjustments to wiring or conguration as needed.
Open the Toolbelt software.
Start Device Discovery.
Toolbelt displays a list of all
Extron control devices connected
to the network.
Using the MAC address, locate the
desired device in the list and select it.
Enter credentials, if needed.
Network Communication Setup
Connect the NBP and PC to the same
network. Apply power to all devices.
Use the Set IP feature in Toolbelt or
use the Toolbelt
Manage
> Network
Settings tab feature
to enable DHCP or to enter the
IP address, subnet address, and
gateway, then congure other
network settings as needed.
Figure 47. Network Setup
47
Rev. D: Added bullet point
about 802.1X reference
material.
Rev. F: Simplified terms
for the control device
to “control processor”
per PM request.,
added mentions of
ControlScript.
Rev. F: Reduced the names
of the various user guides
down to a generic phrase
(user guide for the control
processor) per PM request.
