Network Button Panels • Hardware Features and Installation — NBP 1200C 37
Step 6: Mount the NBP 1200C to the Table
Insert the NBP 1200C Enclosure Into the Table
Remove the plastic
strips and lm on
the surface of the
Cable Cubby.
Ensure that the
side clamps are
seated against
the enclosure.
Lower the Cable Cubby
into the hole to test
the t. If necessary,
carefully enlarge
the opening.
p
l
ast
i
c
m
on
f
th
e
e
e
e
ON
OFF
PC
LAPTOP
MUTE
MEDIA PLAYER
HDMI 1
HDMI 2
e
21-525-
01LF
2
1
3
Figure 41. Inserting the NBP 1200C Enclosure into the Table
Under the Table, Adjust the Side Clamps on the Enclosure
e
ON
OFF
PC
LAPTOP
MUTE
AUX VIDEO
VGA
HDMI
e
21
-525
-
01LF
e
ON
OFF
PC
LAPTOP
MUTE
MEDIA PLAYER
HDMI 1
HDMI 2
1
Rotate the side clamp
outward and ensure
that the lever is down.
Slide the clamp all the
way up against the
bottom of the table.
Ensure the Cable Cubby
is rmly seated in the table.
Raise the lever to secure
the Cable Cubby.
1
e
21-525-01LF
21-526-0
7
e
21-525-01LF
Lever
21 3
e
Figure 42. Securing the Cable Cubby Enclosure
CAUTION: The flanged edges
of the top of the surface
enclosure are sharp. These
edges are also soft and
may be easily nicked or
bent. Exercise caution when
handling the enclosure to
prevent personal injury or
damage to the enclosure.
ATTENTION
: Les extrémités
à brides du haut de la surface
du boîtier sont aiguisées.
Ces extrémités sont aussi
lisses et peuvent facilement
être coupées ou pliées.
Soyez prudents lorsque vous
manipulez le boîtier afin
d’éviter de l’endommager ou
de vous blesser.
41
NOTE: To lower the side clamp, turn the lever
down, then press and hold the locking plate
while sliding down the clamp.
21-526-0
7
Locking
plate
Rev. E: Replaced image
with updated version
from the NBP 1200C
setup guide.
42
