NAV SD 121 Scaling Decoder and NAV D 121 Decoder • Introduction 2
The data stream consists of HDCP-compliant HDMI video (which can include embedded digital audio
[SMPTE 299M and SMPTE 272M-A]) at resolutions up to 4k @ 60 Hz
The streamed NAV signal is routed using a managed network switch and can be dedicated to a specific LAN. AV
switching can be done via a control system by interfacing to the NAV decoder or a NAVigator.
NOTE: The RS-232 and IR communications are driven via a control system. The encoder and decoder do not
generate or respond to the RS-232 and IR communication signals.
About the Decoder
One or more compatible decoders, such as the NAV SD 121 or NAV D 121, decode the data stream back into the
original video and audio signal formats and output them locally.
NOTE: Both decoder models can output embedded digital audio in the HDMI output only.
System Interaction and Capabilities
Each encoder and decoder has an integrated web interface. All normal system configuration
and control is via the web interface of a NAVigator. Using a computer on the same network and a standard web
browser; such as Google Chrome™, Mozilla™ Firefox™, or Microsoft
®
Edge™; you can configure any
encoder or decoder unit in the system.
The embedded audio can be transported as a 2-channel LPCM uncompressed stream. Audio can follow video to
the same decoder or be broken away to a different endpoint.
A dedicated RS-232/IR port and a digital I/O port, part of a secure platform device (SPD), is available for
distributing RS-232 data with the coded/decoded video, such as for control of a projector.
The decoder is housed in 1-inch high, quarter-rack width metal enclosure that can be mounted in any standard
19-inch rack or under furniture with optional mounting kits.
The external 100 VAC to 240 VAC, 50-60 Hz power supply provides worldwide power compatibility.
Features
• Decodes video and audio signals over 1 Gbps Ethernet networks — Standard 1 Gbps Ethernet supports
flexible system design and transmission over large distances to any location.
• Supports HDMI 2.0 at resolutions up to 4K/60 @ 4:4:4 — HDMI up to 4K @ 60 Hz (4096 x 2160) with full
4:4:4 chroma subsampling ensures accurate reproduction of source images.
• PURE3 Codec — Patented by Extron, the wavelet-based compression technology delivers high image quality
with very low-latency at highly efficient bit rates. With its high immunity to network errors and built-in error
concealment, PURE3 facilitates reliable, real-time delivery of visually lossless video over IP networks.
• PURE3 Intelligent Selective Streaming (ISS) — Intelligent Selective Streaming leverages low motion
content to achieve extremely low bitrates while maintaining visually lossless performance.
• Interoperable with 10 Gbps NAV endpoints — 1 Gbps video can be readily decoded by 10 Gbps decoders
for greater compatibility in mixed 1 Gbps/10 Gbps solutions.
• Ultra-low latency with high quality video — Decodes and scales professional-grade video with ultra-low
latency using the unique wavelet-based Extron PURE3 codec, guaranteeing exceptional user experience and
accurate reproduction of every detail.
• Advanced Extron Vector 4K scaling technology (NAV SD 121 only) — Vector 4K scaling technology
ensures critical-quality 4K imagery, with best in class image upscaling and downscaling, enhanced color
accuracy, and picture detail.
• AES67 audio support (NAV SD 121 only) — Supports the AES67 audio over IP standard, providing
compatibility with Extron and third-party DSP processors.
