MLC 64 RS VC D front panel
The MLC 64 RS VC D front panel contains seven buttons, an Activity LED, and a volume
control knob.
AA
B
B
D
D
G
G
F
F
VIDEO
AUX
LAPTOP
PC
Extron
DISPLAY
ON
OFF
MUTE
VOLUME
MUT
E
V
O
L
U
M
E
EE
A
Activity LED
B
Display power On and Off Buttons
D
Input Selection buttons
E
ON button identification nub
F
MUTE button
G
Volume control knob
Figure 7. MLC 64 RS VC D Front Panel
Controls behind the wallplate
The front panels of the MLC D controllers contain some controls and connectors that are
located behind the wallplate when the controller is mounted. To access these features that
are covered during normal operation, you must remove the wallplate (see Accessing the
Covered MLC D Front Panel Features on page 41).
KK
J
J
HH
VOLUME
DISPLAY
E
PC
VIDEO
LAPTOP
MUTE
ON
OFF
MUTE
VOLUME
MUT
E
VO
L
U
ME
AUX
LAPTOP
PC
E
DISPLAY
ON
OFF
VIDEO
MLC 62 RS D
MLC 64 RS VC D
II
H
Reset LED
I
Reset button
J
USB configuration port
K
IR Learning sensor
Figure 8. MLC D Front Panel Controls Behind the Wallplate
MLC 60 Series MediaLink Controllers • Features, Installation, and Operation 11
