Introduction
This section gives an overview of the MLC 55 Series MediaLink Controllers and their
features. Topics include:
• About this Guide
• About the MLC 55 Series MediaLink Controllers
• Device Drivers
• Application Diagrams
About this Guide
This user guide provides detailed information about cabling and configuring the Extron
MLC 55 Series MediaLink Controllers. It also describes the commands that can be used to
control these products remotely.
Throughout this guide the general terms “MLC,” “MLC 55,” and “controller” are used
interchangeably to refer to any MLC 55 Series controller.
About the MLC 55 Series MediaLink Controllers
The Extron MLC 55 Series MediaLink Controllers are panels that control a wide range of AV
systems in any classroom, meeting facility, or auditorium via RS-232 or IR. All models act as
extended remote control panels for a projector, display, or switcher.
The MLCs feature six labeled backlit buttons, which can be configured via the MLC
Windows
®
-based configuration program to control power, input switching, and volume on
a display device or switcher. If desired, you can replace these buttons with ones having
different labels, which also are provided with the controller. The MLC 55 RS VC model has,
in addition to the configurable buttons, a volume control module with a volume control knob.
An Extron amplifier with remote volume port capability can be connected to this module for
volume control via the MLC.
The MLC controllers are housed in secure, compact, one-gang and two-gang sized
enclosures, which can be mounted on a wall or furniture, with or without an electrical
junction box or mounting bracket.
MLC Models
The MLC 55 series consists of the following models (see the next page for illustrations).
NOTE: These models are for use only with UL Listed Extron products.
• MLC 55 RS — US model. Has a one-gang sized faceplate and fits in a one-gang US
junction box.
• MLC 55 RS VC — US model. Has a two-gang sized faceplate and fits in a standard
two-gang US junction box. Contains a volume control module with an analog
potentiometer for use with an Extron amplifier.
NOTE: Only an Extron amplifier with remote volume control capability can be used
with this model.
MLC 55 Series MediaLink Controllers • Introduction 1
