Features
• Configurable buttons — All MLC models have six buttons, prelabeled as shown in
figure 1 on the previous page. These buttons can be set up via the MLC 55, 62 and
64 Series Configuration Program to control display power, volume, input selection, or
any other IR or RS-232 command that the display supports.
A set of button labels is included with each model, enabling you to customize the
buttons to suit the application.
• Dual color button backlighting — The front panel buttons are backlit in white or
red to facilitate use in low-light environments and to provide certain status information
(such as whether power is on or off, or which input has been selected).
• Device drivers — A wide variety of Extron certified, ready-to-use device
drivers are available via the MLC configuration program and the Extron website
(www.extron.com).
• Unidirectional IR and RS-232 ports — Each MLC 55 model has an IR and serial
port for communicating with most types of projectors or flat panel displays via IR or
RS-232. IR and RS-232 display drivers can be downloaded and used to configure the
controller (see Device Drivers on the next page).
• IR Learning — The MLC can be configured by IR learning, using the remote control
of a switcher or display device to create an IR driver that enables the MLC to control
the device.
• USB configuration port — The MLC is configured from the computer via a USB
mini-B port, located on the front panel behind the faceplate.
• Volume adjustment:
• The MLC 55 RS, RS EU, RS EU V, and RS MK models have individual Volume
Up and Down buttons for audio level control.
• The MLC 55 RS VC has a volume control module with a knob to control the
audio level for an Extron amplifier that is enabled for remote volume control.
• Toggling — Buttons can be placed in toggle mode, which adds flexibility by enabling
two different sets of commands to be executed with alternating presses of the button.
• Inactivity timer for display shutoff — An adjustable timer controls automatic
shutdown after a specified period of inactivity.
• Power saving mode — The MLC can be placed in sleep mode for a specified
period to conserve energy.
• Front panel security lockout — If the MLC is installed in an unsecured environment
where easy access is not desirable, a security lockout feature can be implemented to
lock out all front panel controls.
• Section 508 Compliant — The MLC meets or exceeds accessibility standards
for Electronic Information Technology. For more information about the Extron
Commitment to Accessibility, see the Extron Accessibility web page at
www.extron.com/company/article.aspx?id=accessibility.
MLC 55, 62 and 64 Series Configuration Program
The MLC 55, 62 and 64 Series Configuration Program is used to configure the MLC
buttons and ports via a USB connection. This program, downloadable from the Extron
website, enables you to set functions for the front panel buttons and to configure the MLC
ports in order to control devices via the MLC. The program works in combination with the
IR or RS-232 device drivers, also available at www.extron.com (see Downloading and
Installing the Configuration Program on page 29 to access this program).
MLC 55 Series MediaLink Controllers • Introduction 3
