IPL EXP I/O Series • Hardware Features and Installation 18
LAN/PoE and LAN/PoE+ (Ethernet) connectors and LEDs
To connect the EXP to an Ethernet network (for conguration and control of the EXP and the devices connected
to it), plug a cable into one of these RJ-45 sockets and connect the other end of the cable to a power inserter,
network switch, hub, router, or PC connected to a local network or the Internet. DHCP is o by default.
• The IPL EXP RIO8 requires a PoE+ connection through its LAN/PoE+ port see the power input requirement
on page 14).
• All other IPL EXP models accept power over Ethernet (PoE) and PoE+ through the LAN/PoE port
ATTENTION:
• Power over Ethernet (PoE) is intended for indoor use only. It is to be connected only to networks or
circuits that are not routed to the outside plant or building.
• L’alimentation via Ethernet (PoE) est destinée à une utilisation en intérieur uniquement. Elle doit être
connectée seulement à des réseaux ou des circuits qui ne sont pas routés au réseau ou au bâtiment
extérieur.
Network Port Addressing:
If you use static IP addresses, congure the settings and IP addresses via Toolbelt. See the help le for Global
Congurator or Toolbelt for basic information on conguration. See gure 8 on the next page and see the
following table for default addresses.
Network Port Addressing
IP Address Subnet Mask DNS Address
Static IP addresses (default, what the unit uses when DHCP is off)
192.168.254.250 255.255.255.0 127.0.0.1
DHCP on (alternative setting)
DHCP on (addresses are automatically assigned)
For details of communication protocols, ports, and services used, see the Control Systems Network Ports,
Protocols, and Licenses Guide at www.extron.com.
LED Indication:
Activity LED (connectors [all models] and front panel [rack mount models]) —
This yellow LED blinks to indicate network activity.
Link LED (connectors [all models] and front panel [rack mount models]) —
This green LED lights to indicate a good network connection.
100 LED (IPL EXP RIO8 front panel) —
This green LED lights when the unit is connected to a 100 Mbps or faster network connection.
Passwords:
IMPORTANT NOTE:
The factory configured passwords for this device have been set to the device serial number. Passwords are
case sensitive. Performing a Reset to Factory Defaults reset (see Resetting the Unit on page 27) sets the
password to
extron
.
