IPCP Pro Q xi and xi Series • Hardware Features and Installation 17
IPCP Pro PCS1 xi-Specific Front Panel Features
Power button (switch) and LED
The front panel power button (switch) provides a way to manually turn switched AC power output
on or o for the rear panel AC power output cable on the IPCP Pro PCS1 xi.
NOTE: The button is not a safety disconnect device. In case of an emergency, disconnect
AC power from the power input (appliance inlet) of the connected equipment.
The IPCP Pro PCS1 xi can be congured (using Global Congurator or ControlScript programming software)
to monitor the power output condition and to alert users in the event of a power fault interruption. The
IPCP Pro PCS1 xi can be set up to monitor the circuit breaker and also the current load at the switched AC power
output port.
NOTE: The power output state setting persists after a power cycle.
The AC power LED on the IPCP Pro PCS1 xi lights to indicate the power output state as follows:
Lit green: Power output is enabled.
O (dark): Power output is disabled.
Lit red: A fault condition is detected, and power output is disabled.
Front panel lockout (executive mode)
To prevent unauthorized use, the power button can be locked (disabled) via a front panel lockout mode (executive
mode) that can be enabled or disabled by one of two methods:
• Using software, as part of the configuration or when programming actions, monitors, or schedules
• Pressing and holding down the
Power
button for 3 seconds
The power LED blinks three times to indicate the lockout mode has been enabled or disabled.
When the front panel is locked, if the
Power
button is pressed, the power LED blinks three times to indicate that
the button is locked, and the unit does not change power states as a result of the button press.
NOTE: The executive mode state (on or off) persists after and is retained during a power cycle.
Circuit breaker
The front panel features a 10 A rated circuit breaker. When a fault condition occurs, the breaker
is triggered, which stops power output. This condition can be monitored and the system can be
congured (using available commands) to send an alert e-mail or perform some other action. After
you correct the cause of the overcurrent condition, press the
Breaker
button to manually reset the
circuit breaker.
NOTES:
• The circuit breaker and the
Reset
button are not affected by front panel lockout (executive mode)
settings.
• The embedded web page for the unit displays the state of the circuit breaker and the value of the
combined current load.
POWER
Rev. B: Deleted
“convenient”.
Rev. D: Added
ControlScript
Deployment Utility.
Rev. B: Deleted “and is
retained” from note per
Tameem Breik.
10
BREAKER
10
P
R
E
S
S
T
O
R
E
S
E
T
When an overcurrent condition occurs, such as a short
circuit or circuit overload
