Command and Response Table for Receiver SIS Commands (continued)
FOXBOX Tx/Rx HDMI • Remote Control 26
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Video shutdown delay
NOTES:
• The Set Video Delay command delays the digital video to help monitors sync correctly during an input rate change.
• Only video is delayed; embedded audio is not delayed.
Set delay
3*
X2@
# Dly
X2@]
Delay video by an interval of
X2@
.
Example:
3*3#
Dly3
]
Delay video by an interval of 0.75
seconds (3 x 0.25 seconds).
View delay
3#
X2@]
Switch and signal status
requests
Request Audio switch status
E
Stat
} X1&]
Show the position of the Audio switch:
0 = off (embedded audio is muted) or
1 = on (unmute).
NOTE: The audio on the captive screw audio output always remains active regardless of the setting of this switch.
Check audio embed
E
5Stat
}
EmbedAud
X1@]
Show if audio is embedded in the
video stream:
0 = not detected or 1 = detected.
View link 1 (Tx-to-Rx) status
1S
X1@]
View link 2 (Rx-to-Tx) status
2S
X1@]
View input video status
3S
X1@]
View input audio status
4S
X1@]
View all signal status
5S
SigI
X1@
•
SigO
X1@
•
HdcpI
X1@
•
HdcpO
X1@]
Report the status of the HDMI input,
HDMI output, HDCP encoding on the
input, and HDCP encoding on the
output.
View HDMI signal status
6S
SigI
X1@
•
SigO
X1@]
Report the status of the HDMI input
and HDMI output (always -- for a
transmitter).
View HDCP status
7S
HdcpI
X1@
•
HdcpO
X1@]
Report the status of the HDCP
encoding on the input and HDCP
encoding on the output.
View temperature
20S
X1#
F
•
X1#
C
]
Show temperature in degrees
Fahrenheit and Celsius.
KEY:
X1@
= Link status 0 = light or signal input not detected
1 = light or signal detected
X1#
= Internal temperature nnnF•nnC
X1&
= Switch position 0 = off (right) 1 = on (left)
X2@
= Video delay 0 = 0 second
(0 plus six steps at 0.25 seconds per step) 1 = 0.25 second 3 = 0.75 second 5 = 1.25 second
2 = 0.5 second (default) 4 = 1.0 second 6 = 1.5 second
