FOX3SR 301 and FOX3SR311 Scaling Receivers • Internal Web Page 46
Firmware Panel
The Firmware panel (see figure35,
7
on page42) displays the current firmware version
and the date it was last updated. Update the firmware on the FOX3SR301/311 from this
panel (see Software/Firmware Installation on page32 to download the firmware files).
To update firmware:
1. In the Firmware panel, click the SELECT
FILE button (see figure42).
2. In the Open dialog box, browse to locate
the new firmware file on your computer (by
default the file is stored at C:\Program
Files (x86)\Extron\Firmware\
FOX3 SR 301/311 after being downloaded
from www.extron.com).
NOTE: Firmware files for FOX3SR
301 and FOX3SR311 have a .eff
extension. Do not attempt to load any
other file types.
3. Double-click the firmware file name. The
Open window closes, and the selected
firmware file name appears in the Update
Firmware panel on the web page.
Figure 42. Firmware Panel
4. Click INSTALL to begin.
To cancel the update, click the X button in the Update Firmware panel.
During the updating process, a window appears in the middle of the screen, showing
messages giving the progress of the update: Initializing, Installing the
Firmware, and Rebooting Device.
When the update is completed, the message window closes and the message Firmware
Upload Complete appears near the top of the screen. The new firmware filename appears
beside Version in the Firmware panel.
42
