FOX3SR 301 and FOX3SR311 Scaling Receivers • Configuration Software 33
4. Scroll down to the alphabetic navigation bar (see figure18).
Figure 18. Software Installation
5. Click the appropriate letter to locate the software or firmware.
6. Click Download and follow the on-screen instructions (see figure19,
1
for PCS).
Figure 19. PCS Software Download
For Firmware:
Figure 20. Firmware Page with Alphabetic Navigation Bar
NOTE: The device is not in the list if there is no firmware update available.
a. Click the letter F from the alphabetic navigation bar (see figure20,
1
).
b. Scroll down the page to find the firmware for the FOX3SR301/311.
c. (Optional) Click Release Notes (
2
) for more information about the firmware
update.
d. Click Download (
3
). The product download screen opens.
e. Enter the required user information and click Download. An executable (.exe) file is
downloaded to the PC. Run this program to place the firmware on the PC for future
use. Make a note of the folder where the firmware file was saved.
7. Install the software.
a. Navigate to the folder where the software file was downloaded.
b. Double-click the executable file and follow the on-screen directions to install the
software.
For Firmware:
a. To install via PCS, see Update Firmware in the Device Menu on page39.
b. To install via the internal web pages, see the Firmware Panel on page46.
18
step 6
19
20
