Extron DTP T UWP 4K D Series • Introduction 2
Twisted Pair Cable Advantages
Twisted pair cable is much smaller, lighter, more flexible, and less expensive than coaxial
or HDMI cable. These transmitter and receiver twisted pair (TP) products make cable runs
simpler and less cumbersome. Termination of the cable with RJ-45 connectors is simple,
quick, and economical (see Twisted Pair Recommendations for DTP Communication
on page 8 for more information).
NOTE: Do not use Extron UTP23SF-4 Enhanced Skew-Free AV UTP cable or STP201
cable to link the transmitter and receiver. The DTP T UWP 4K D series does not work
properly with these cables.
Control Communications
The RS-232 communications are pass-through only. The transmitter and receiver do not
generate or respond to these signals.
Transmission Distance
The maximum transmission distance is determined by the resolution of the signal and the
twisted pair cable, graphics card, and display used in the system.
• DTP T UWP 4K 232 D transmitters can transmit 720p, 1080i or 1080p HDTV video,
and 4K signals up to 230 feet (70 meters) over STP cable.
• DTP T UWP 4K 332 D transmitters can transmit 720p, 1080i or 1080p HDTV video,
and 4K signals up to 330 feet (100 meters) over STP cable.
Features
Transmits HDMI or VGA signals over one STP cable — Twisted pair cables provide an
economical, easily installed cable solution.
Supports computer and video resolutions up to 4K
Supports DDC and HDCP transmission — The transmitters fully support long distance
transmission of the DDC and HDCP signals.
Control communications pass-through — Bidirectional RS-232 control signals can be
transmitted alongside the HDMI signal, so that the remote display can be controlled without
the need for additional cabling.
Analog stereo audio embedding — Analog stereo audio signals can be selectively
embedded onto the digital video output signal and transported over DTP. The HDMI inputs
can be set to pass the embedded digital audio, embed the analog audio, or to automatically
embed the analog audio when no digital audio is detected.
External 100 VAC to 240 VAC, 50-60 Hz, international power supply — Included with
transmitters.
Remote powering of the transmitter or receiver — Only one power supply is necessary
to power both devices.
