Extron DTP T UWP 4K D Series • Installation and Operation 3
Installation and
Operation
This section describes the installation and the operation of the extenders, including:
• Mounting the Transmitter
• DTP T UWP 4K D Connections
• Twisted Pair Recommendations for DTP Communication
• Power Supply Wiring
• RS-232 Connector Wiring
• Operation
Mounting the Transmitter
ATTENTION:
• Installation and service must be performed by authorized personnel.
• L’installation et l’entretien doivent être effectués par le personnel autorisé
uniquement.
• The unit must be installed in accordance with the National Electrical Code and with
local electrical and safety codes.
• L’unité doit être installée conformément au National Electric Code et aux normes
électriques et de sécurité locales.
The transmitters can be installed in a two-gang electrical wall box, or with a mud ring with a
decorator-style wallplate cover (supplied).
UL and Safety Guidelines
The following UL guidelines pertain to the installation of the decorator-style wallplate
transmitters into a wall or furniture.
• These units are not to be connected to a centralized DC power source or used beyond
their rated voltage range.
• These units must be installed in UL-listed wall boxes.
• These units must be installed in a UL-listed junction box with a UL-listed faceplate.
• This product is intended to be supplied by a power source marked “Class 2” or “LPS”
rated 12 VDC, minimum 1.0 A
