DTP T USW 333 • Introduction 2
STP Cable
Extron recommends XTP DTP 24 shielded twisted pair (STP) cable for best performance. Extron recommends at
least 24 AWG, solid conductor, STP cable with a minimum bandwidth of 400 MHz.
ATTENTION:
• Do not use Extron UTP23SF-4 Enhanced Skew-Free AV UTP cable or STP201 cable to link the
switching transmitter and receiver. The DTP T USW 333 does not work properly with these cables.
• N’utilisez pas le câble AV Skew-Free UTP version améliorée UTP23SF d’Extron ou le câble STP201
pour relier les produits XTP avec les émetteurs ou les récepteurs DTP.
Twisted pair cable is smaller, lighter, more flexible, and less expensive than coaxial cable. The DTP 330-enabled
products make cable runs simpler and less cumbersome. Termination of the cable with RJ-45 connectors is
simple, quick, and economical.
Control Communications
Control this device through the front panel USB port, the rear panel RS-232 port, or through a DTP matrix. The
RS-232 and IR communications are pass-through only. The switching transmitter and receiver do not generate or
respond to the RS-232 and IR communication signals.
Features
• Transmits HDMI or analog video, control, and analog audio up to 330 feet (100 meters) over a shielded
CATx cable — Provides high reliability and maximum performance on an economical and easily installed
cable infrastructure.
• Inputs: Two HDMI, one VGA on 15-pin HD, one 3.5 mm stereo mini jack for audio
• Output: One DTP 330 twisted pair output on RJ-45
• Auto-switching between inputs — Auto-switching allows for simple, unmanaged installation in locations
such as in a lectern or under a conference table. When multiple inputs are active, the switching priority is
configurable.
• Supports computer and video resolutions up to 1920x1200, including 1080p/60 and 2K — Supports
digital signal transmission up to 330 feet (100 meters) over a shielded twisted pair cable and maintains
superior image quality at the highest resolutions.
• Analog stereo audio embedding — Analog stereo audio signals can be selectively embedded onto the
digital video output signal and transported over DTP. The HDMI inputs can be set to pass the embedded
digital audio, embed the analog audio, or to automatically embed the analog audio when no digital audio is
detected.
• Remote power capability — For simplified installation, the transmitter can be remotely powered by a DTP
330-enabled product over the twisted pair connection.
• Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for optimal performance.
• Compatible with CATx shielded twisted pair cable — Fully supports a maximum transmission distance of
330 feet (100 meters) for all compatible resolutions when used with CATx shielded twisted pair cable.
Shielded twisted pair cabling with solid center conductor sizes of 24 AWG or better is recommended for
optimal performance.
• Accepts additional analog stereo audio signals — Accepts stereo analog audio signals for simultaneous
transmission over the same shielded twisted pair cable.
• Audio input assignment — The analog audio input can be assigned to any video input, or it can be set to
follow the input switch.
• Adjustable audio input gain — Gain can be adjusted for the analog audio input via SIS commands to
eliminate noticeable differences when switching between sources.
