DTP CrossPoint 4K Series Matrix Switchers • Introduction 4
• Preset — A full or partial configuration (a subset of ties, sets of ties, or signal processor settings) with
accompanying audio settings that has been stored and can be retrieved.
NOTES:
• PresetscanbecreatedonlybyusingtheDSPConguratororProductCongurationSoftware
programs.
• Whenapresetisretrievedfrommemory,itbecomesthecurrentconguration.
• Up to 32 partial or full presets can be stored in memory. Preset locations are assigned to the input
buttons and output buttons. Up to 18 preset locations can be recalled from the front panel. Preset
numbers larger than 18 are accessible under remote control.
• PresetscanalsoberecalledusingSIScommands,usingtheProductCongurationSoftware,or
usingtheDSPConguratorprogram.
• Whenapresetconsistingoffullcongurationsisrecalled,itcompletelyoverwritesthecurrent
conguration.
• Whenapresetconsistingofoneormorepartialcongurationsisrecalled,itoverwritesonlya
portionofthecurrentconguration,leavingothertiesandsettingsunchanged.
Features
• All-in-one matrix switcher, scaler, and audio DSP — The DTP CrossPoint 4K Series delivers all of the
core functionality of a conventional AV system in a single enclosure, making it ideal for presentation
environments that require multiple displays.
• Audio power amplifier — The SA and MA models feature amplifiers for sound reinforcement.
• Inputs —
• Six HDMI
• Four or two DTP twisted pair inputs on RJ-45 connectors
• Six stereo balanced or unbalanced audio inputs on captive screw connectors
• Four mic/line audio inputs on captive screw connectors
• Outputs —
• Six or four HDMI
• Four or two independently scaled DTP twisted pair outputs on RJ-45
• One S/PDIF (Sony/Philips Digital Interface Format) digital audio output on an RCA connector
• Four or two variable audio outputs on captive screw connectors
• (SA and MA models) One variable amplified speaker output
• SA models — 5 mm, 4-pole captive screw connector
• MA models — 5 mm, 2-pole captive screw connector
• Integrated DTP inputs and outputs — Support digital transmission of HDMI or DVI plus video, control,
and audio up to 330 feet (100 meters) over a shielded twisted pair (STP) cable, providing high reliability
and maximum performance on an easily installed cable infrastructure.
• Supports 4K and UHD signals at all inputs and on both HDMI outputs — Incoming 4K and UHD
signals are supported at all HDMI and DTP inputs, and can be passed only to the HDMI outputs.
• Selectable scaled DTP output rates — From 640x480 to 1920x1200, including HDTV 1080p/60, and 4K
(4096x2160). The output rate can be individually selected for each of the two scaled DTP outputs.
Available output rates include computer-video up to 1920x1200, HDTV rates up to 1080p/60, and
4096x2160.
