11. If this is the only device to which firmware is being uploaded to, click Add (see
figure19,
2
on page18). The distribution amplifier information is added to the
Device section of the Firmware Loader window and the Add Device window closes.
If uploading firmware to multiple distribution amplifiers that are connected to the
computer, do the following:
a. Click Add Next (
3
). Your first device is added to the Device section of the
Firmware Loader window, and the Add Device window remains open.
b. For each additional device added to the Firmware Loader window, repeat steps 5
through 11, then click Add Next.
c. For the last device, click Add (instead of Add Next) to add the device and close the
Add Device window.
11
Figure 20. Firmware Loader Screen with a DA4 12G HD-SDI Added
12. To remove a device from the Device section, do the following:
a. Click on the names of the devices to be deleted, to highlight them.
b. From the Edit menu (see figure21,
1
), select Remove Selected Device(s) (
2
).
11
2
2
3
3
Figure 21. Firmware Loader Edit Menu
c. Select Remove All Devices (
3
) from the Edit menu to remove all devices.
13. Click Begin (see figure20,
1
).
20
21
DA4 12G HD-SDI • Configuration Software 19
