4. Open the Firmware Loader program via the Firmware Loader icon installed during the
download (optional) or the desktop Start menu by making the following selections:
Start>All Programs>Extron Electronics>FirmwareLoader>Firmware Loader
The Firmware Loader window opens with the Add Device... window in front (see
figure16).
Figure 16. Opening Firmware Loader
5. In the Add Device window, select the appropriate DA412GHD‑SDI from the Device
Names drop‑down menu.
6. From the Connection Method drop‑down menu, select USB.
7. Make the appropriate selections for your connection method.
• USB: Only the Extron USB Device_0 option is available on the
Available Devices menu. Make sure it is selected.
8. Click Connect. If the connection is successful, the unit name is displayed in green in the
Connected Device section, followed by a green check mark (see figure17,
1
).
11
2
2
DA4 12G HD-SDI
DA4 12G HD-SDI
DA4 12G HD-SDI\da412ghd-sdi_A_v1.00_1.
Figure 17. Add Device Window Browse for Firmware
9. Click the Browse button in the New Firmware File (Optional) section (
2
).
10. In the Open window (see figure18 on page18), navigate to the new firmware file,
which has an .S19 extension, and double‑click it.
16
17
DA4 12G HD-SDI • Configuration Software 17
