1
Thank you for purchasing this RS232/TTL(CMS) to USB2.0 Adapter. It is
an intelligent expansion module that connects to a PC or server via
the Universal Serial Bus (USB2.0), providing a high-speed serial
connectivity to either RS232 or TTL/CMOS signal device. The serial port
provides RS232 signals on DB9 and TTL/CMOS signals on the 5-pin
terminal blocks respectively (only one works at a time, not
simultaneously). They are fully compatible with RS232 and TTL/CMOS
standard logic level. With the complete bundled virtual COM port
drivers, wall and DIN RAIL flexible mounting options, it is an ideal
solution for most critical and industrial applications.
EX-1331TTL-VIS
RS232/TTL(CMOS) to USB2.0 Adapter, w/
Isolation and Surge Protection
1. Introduction
DB9 male connector:
RS232 signals
2. Connector Layout
Rear Panel:
USB Type B Connector
TB-5 connector:
TTL/CMOS signals
Wall Mounting Kit
LED:
Power and
Activity
