Appendix E Extended Remote Connections
Page 48 Appendix E Connections BD600+ Profanity Delay
Document Version 2.3
Parallel Inputs
The parallel inputs are opto-isolated and bipolar, meaning that they may be driven by a positive or a
negative voltage. This voltage may range between 5 and 25 volts.
One side of each input is commoned in groups of 4. By default, all these groups of common connec-
tions are tied together. This may be changed by the use of internal jumpers P100-103 – if these are all
removed the inputs will be isolated from ground and from the other groups of 4.
(1) Chassis Ground
(14) Signal Ground
(2) In 1
(15) In 9
(3) In 2
(16) In 10
(4) In 3
(17) In 11
(5) In 4
(18) In 12
(6) Common 1-4
(19) Common 9-12
(7) In 5
(20) In 13
(8) In 6
(21) In 14
(9) In 7
(22) In 15
(10) In 8
(23) In 16
(11) Common 5-8
(24) Common 13-16
(12) no connection
(25) no connection
(13) +5V 0.5A
Notes
• None of the ground or common connections may be used as a safety ground – they are rated for
low current DC operation only.
• The Chassis Ground connection (1) may be used as a cable screen connection. It should not be con-
nected otherwise.
A simple circuit for triggering DUMP:
With factory default settings, connect your push-button between pins 3 and 13, and connect pins 6 and
14 together.
