15
7
Place the main flue with the stability bracket secured, onto the rangehood and mark
on the wall the points where the bracket should be fixed (x), figure 5 and then remove
the flue and set aside, ready for the next step. If required, place suitable fixings where
the holes were marked, ready for installation of the stability bracket in step 10.
8
Slide the flue extension into the main flue, figure 6. Place the flue set onto the
rangehood allowing it to sit loosely on top of the rangehood but not locked
into position, figure 7.
INSTALLATION
6 7
5
Flue
extension
