14
3
Directly above the flue extension bracket, cut a 155mm diameter hole in the
ceiling for ducting to pass through. The edge of the hole should start no further than
10mm away from the wall to ensure it is covered by the flue extension, once in place.
4
Feed 150mm ducting down through the hole in the ceiling and
leave loose until ready to connect to the outlet on the rangehood.
5
Hang the rangehood on the wall by tilting it on a slight angle and
liing it onto the bracket so that protruding hooks interlock with the
mounting holes at the back of the rangehood, figure 3.
6
Secure the stability bracket to the main flue using the supplied fixing screws, figure 4.
INSTALLATION
43
Stability
bracket
Main flue
