EN - 11
A
B
C
C
D
E
LPG: Gas pressure must be adjusted to
2.75 kPa.
The flexible hose assembly must be
certified to AS/NZS 1869 class B or D, be
of appropriate internal diameter for the total
gas consumption (10mm), be kept as short
as possible (not exceeding 1200mm), must
not be in contact with the floor or any hot
surface or sharp surface. the hose
assembly must not be subject to strain,
abrasion, kinking, deformation or contact
with any other appliance.
Gas leakage and operation of the
appliance must be tested by the installer
before leaving. Check burner flames are
blue in colour, stable and completely ignite
at both high and low flame settings with no
appreciable yellow tipping, carbon
deposition, lifting, floating, lighting back or
objectionable odour. Test burners
individually and in combination. When
satisfied with the operation of the cooker,
please instruct the user the correct method
of operation.
2.3 Gas Connection
Assembly of gas supply and leakage
check
Connect the appliance in accordance with
applicable local and international
standards and regulations. First, check
what type of gas is installed on the
cooker. This information is available on a
sticker on the back of the cooker. You can
find the information related to appropriate
gas types and appropriate gas injectors in
the technical data table. Check that the
feeding gas pressure matches the values
on the technical data table, to be able to
get the most efficient use and to ensure
the minimum gas consumption. If the
pressure of used gas is different than the
values stated or is not stable in your area
it may be necessary to assemble an
available pressure regulator on the gas
inlet. You should contact an authorised
service centre to make these adjustments.
This appliance is suitable for connection
with rigid pipe or flexible hose. The
isolating manual shut-off valve connection
point must be accessible when the
appliance is installed. Inlet connection is at
rear 50mm from the edge.
Natural Gas: The supplied regulator must
be fitted to the appliance inlet connection.
Gas pressure must be adjusted to 1.0kPa
when approximately 50% of the burners
are on a high flame, the appliance test
point is located on the regulator.
Overall appliance dimensions
(WxDxH)
600mm x 600mm x 900mm
Clearance from combustible
materials:
200mm sides from the edge
of the nearest burner.
600mm overhead from the
top of the trivets.
