40CH 40- channel mode

42CH 42- channel mode

Operating

mode

MODE

(Work Mode)

DMX Mode

Setting DMX mode

Auto Mode

Auto Prog 1 - 9 Select Auto Programm 1 - 9

Auto Speed 000 - 255

000-127 speed from fast to slow

128-255 backwards, speed from slow to fast

Manual Mode

1. Red Red intensity 000 – 255

see CH 15 mode

2. Green Green intensity 000 – 255

3. Blue Blue intensity 000 – 255

4. Warm white Warm white intensity 000 – 255

5. Master dimmer Master dimmer 000 – 255

6. Strobe Strobe 000 – 255

7. Dimmer fade Dimmer fade 000 – 255

8. Static macros Static macros 000 – 255

9. Animated macros Animated macros 000 – 255

10. Animated sound Animated sound 000 – 255

11. Animated speed Animated speed 000 – 255

12. Red back Red background 000 – 255

13. Green back Green background 000 – 255

14. Blue back Blue background 000 – 255

15. Warm white back Warm white background 000–

255

M/S Choose Auto/Master/Slave Auto/Master/Slave mode

Display-

settings

DISP

(Display)

Screen saver OFF/Mode1/Mode2

OFF, display will stay on all the time

Mode1, display will turn off in 30 seconds without

operating

Mode2, display will show “XXX” DMX address

Screen Rev. NO/YES Display reverse

Screen Light

001 – 010

Select brightness

Screen Lock

OFF/ON

Select display lock

Advanced

settings

ADVA

(Advanced)

Network

2.x.x.x

Comm Choose

DMX&NET

Setting DMX&NET/Art-Net

IP Address 2.0.0.5

Settting IP address

Subnet Mas 255.0.0.0

Setting subnet mas

Universe 0

Setting Universe

DHCP OFF

Select DHCP ON/OFF

sACN OFF

Select sACN ON/OFF

Data hold

OFF/ON

Select DMX lost status

Pixel Dir

Normal/Invert

Setting LED pixel direction

Factory

Setting

NO/YES Factory default setting

Fixture Status

Light Temp xx°C

Panel Temp xx°C

Sensor 1 Temp Xx°C

Temperature LED circuit board

Temperature on the display circuit board

Temperature on the control circuit board

Version

C8.1.0

Manufacturer

Steinigke

Device

Eurolite

Model

10 RGB/WW

Show version number

*Channel mode can´t be changed when the fixture is in manual mode.
