INSTALLATION

WARNING! Risk of injury caused by falling objects

Devices in overhead installations may cause severe injuries when crashing down. Make sure

that the device is installed securely and cannot fall down. The installation must be carried out by

a specialist who is familiar with the hazards and the relevant regulations.

DANGER! Damage caused by laser radiation

Observe the chapter safety instructions when installing the device.

This product is designed for overhead rigging to a wall or ceiling with the mounting brackets. Alternatively, it

can also be fastened to a truss using appropriate couplers.

1 The rigging structure must support at least 10 times the weight of all fixtures to be installed on it.

2 Block access below the work area and work from a stable platform when installing the device.

3 Use rigging hardware that is compatible with the structure and capable of bearing the weight of the

device. Please refer to the Accessories section for a list of suitable rigging hardware.

4 Secure the device with a safety bond or other secondary attachment. This secondary safety attachment

must be sufficiently dimensioned in accordance with the latest industrial safety regulations and

constructed in a way that no part of the installation can fall down if the main attachment fails. An

appropriate eyelet is mounted on the device for fixation of the safety bond. Fasten the safety bond in

such a way that, in the event of a fall, the maximum drop distance of the device will not exceed 20 cm.

5 To align the device, release the fixation screws at the mounting brackets, adjust the desired inclination

angle and retighten the fixation screws.

6 Make sure not to point the laser beams at highly reflective surfaces such as mirror balls, windows and

shiny objects. As a precaution, remove or cover up highly reflective objects in order to avoid laser

reflections.

7 After installation, the device requires inspections periodically to prevent the possibility of rot, deformation

and looseness.

Mounting coupler Mounting coupler

Fixation screws

Safety bond
