00137589.DOCX, Version 1.0

32/40

Sound control

1 Press the button MENU so many times until SOU appears on the display and confirm with ENTER. The

LED indicating sound control mode next to the display will light up.

2 Use the buttons UP and DOWN to select the number of the desired program (SO01- SO14).

3 Confirm with the ENTER button.

4 Adjust the microphone sensitivity to the volume of the music with the SENSITIVITY rotary dial. The LEDs

and the laser will switch off after 5 seconds if the volume is too low or if there is no sufficient bass beat.

Master/slave operation with several laser bars

When several devices are interconnected, the slave units can be synchronized and controlled with the

master unit. The units must be set to the corresponding operating modes.

1 Set all slave units to slave mode: Press the button MENU so many times until SLA appears on the

display. Confirm with the ENTER button. The LED indicating slave mode next to the display will light up.

2 Set the master unit to the desired show program. The interconnected devices will now operate

synchronously.

Remote control IR-16

The IR remote control allows convenient control of the integrated show programs in automatic mode or

sound-controlled mode. Press the buttons repeatedly to switch between the programs. The display indicates

the current setting. When actuating a button, always hold the remote control in the direction of the sensor at

the control unit’s front or rear. There must be visual connection between the remote control and the sensor.

Note: Operation via IR remote control not possible in DMX or slave mode.

Button Function

On/off

Auto mode: Repeated pressing switches programs from 1 - 14

Sound control: Repeated pressing switches programs from 1 - 14

Pause

Decreasing speed in Auto mode

Increasing speed in Auto mode

No function

–

Speed adjustment: 0 is lowest, 9 is highest speed

Switches between Auto mode and Sound control

No function
