ENVR104/ENVR108 Quick Start Guide
Chapter 1 Rear Panel Interfaces Description
The rear panel interfaces vary with different models. Refer to Table 1-1 for the common interfaces description.
Common Interfaces Description of Rear Panel
Chapter 2 Installation and Connections
Device Installation
During installation of the device:
⚫ Use brackets for rack mounting.
⚫ Ensure ample room for audio and video cables.
⚫ When routing cables, ensure the bend radius of the cables are no less than five times of its diameter.
⚫ Allow at least 2 cm (≈0.75 inch) of space among racks mounted devices.
⚫ Ensure the device is grounded.
⚫ Environmental temperature should be within the range of -10 °C to 55 °C (14 °F to 131 °F).
⚫ Environmental humidity should be within the range of 10% to 90%.
Item
Description
Item
Description
VIDEO IN
BNC interface for Turbo HD and
analog video input
VIDEO OUT
BNC connector for video output
AUDIO IN
RCA connector for audio input
AUDIO OUT
RCA connector for audio output
LINE IN
RCA connector for two-way
audio input
USB
Universal Serial Bus (USB) interface
for mouse, keyboard, or USB flash
drive
VGA
DB15 connector for local video
output and menu display
HDMI
HDMI interface for video output
RS-485
RS-485 serial interface for
pan/tilt unit, speed dome, etc
RS-232
RS-232 interface for parameter
configuration, or transparent
channel
LAN
RJ-45 self-adaptive Ethernet
interface
eSATA
Storage and expansion interface for
record or backup
ALARM
IN/OUT
Alarm input/output interface
GND
Ground
Power
Switch
Switch for turning on/off the
device
Power
Supply
100 to 240 VAC, 48 VDC, or 12 VDC
power supply, different models vary
