12
ED3541 Industrial Ethernet Extender User Guide
10/100 Mbps RJ-45 Port
The ED3541 Hardened Ethernet Extender has one 10/100 Mbps RJ-45 port (see Figure 2-1).
This port is auto-sensing, auto-MDIX 10/100 Mbps port.
When you insert a cable into an RJ-45 port, the Hardened Ethernet Extender:
Determines whether the cable is a straight-through or crossover cable.
Automatically ascertains the maximum speed (10 or 100 Mbps) and duplex mode (half- or
full-duplex) of the attached device.
After determining this information, the Hardened Ethernet Extender configures the RJ-45 port
automatically to enable communications with the attached device, without requiring user
intervention.
Ethernet Extender Port
The ED3541 Hardened Ethernet Extender has one Ethernet Extender port (RJ-11 connector
or Terminal Block, see Figure 2-1).
Insert the voice grade copper wire between one pair of Ethernet Extenders via Ethernet
Extender port (RJ-11 connector or Terminal Block).
LEDs
The ED3541 front panel LEDs show power and link/activity status. Table 2-1 summarizes the
LEDs on the Hardened Ethernet Extender.
