ED3501 Industrial Ethernet Extender User Guide
Preparing the Site
Before you install your Industrial Ethernet Extender, be sure your operating environment
meets the operating environment requirements in Table 2-2.
Table 2-2. Site Requirements
Characteristics
Requirements
Mounting
Desktop installations:
DIN-Rail installations:
Wall Mounting installations:
Provide a flat table or shelf surface.
Top hat type 35mm.
Wall Mounting on the wall.
Access
Locate the Industrial Ethernet Extender in a position that lets you access the front panel RJ-45 port
and Ethernet Extender port, view the front panel LEDs, and access the rear-panel power connector.
Power source
Provide a power source within 6 feet (1.8 meters) of the installation location. Power specifications
for the Industrial Ethernet Extender are shown in Appendix A. Be sure the AC outlet is not controlled
by a wall switch, which can accidentally turn off power to the outlet and the Industrial Ethernet
Extender.
Environmental
Temperature:
Install the Industrial Ethernet Extender in a dry area, with ambient temperature between -10 and
60ºC (14 and 140ºF). Keep the Industrial Ethernet Extender away from heat sources such as direct
sunlight, warm air exhausts, hot-air vents, and heaters.
Operating humidity:
The installation location should have a maximum relative humidity of 95%, non-condensing.
Ventilation:
Do not restrict airflow by covering or obstructing the rear and side panels of the Industrial Ethernet
Extender. Keep at least 2 inches (5.08 centimeters) free on all sides for cooling.
Be sure there is adequate airflow in the room where you intend to install the Industrial Ethernet
Extender.
Operating conditions:
Keep the Industrial Ethernet Extender at least 6 ft (1.83 m) away from nearest source of
electromagnetic noise, such as a photocopy machine.
Stacking
If you intend to stack two or more Industrial Ethernet Extenders, be sure:
The mounting surface can safely support the stack.
There is adequate space around the stack for ventilation and cooling.
Installing the Industrial Ethernet Extender
You can install your Industrial Ethernet Extender on a flat surface, DIN-Rail, or wall with other
equipment.
If installing the Industrial Ethernet Extender on a desktop, shelf, DIN-Rail, or wall, allow
sufficient ventilation space between the device and the objects around it.
ED3501 Industrial Ethernet Extender Dimensions: 80.3mm (W) x 109.2mm (D) x 23.8mm
(H) (3.16” (W) x 4.3” (D) x 0.94” (H))
