Button "AUTO" - automatic setting suction power increasing (C3)

- press C3 to switch on automatic suction power adjustment depending of the

level of pollution (if this mode is active, indicator lamp C5 is on)

- press C1 or C2 to switch off this mode (indicator lamp C5 goes off)

Note

Floor nozzle G and small turbo brush H have electronic protection against rotation brush

blocking. If the rotation brush has been blocked during operation, observe the following

instructions.

– If the rotation brush of the floor nozzle G has been blocked during operation, LEDs

G2 go off, the rotation brush stops rotating and indicator lamp C4 goes on. The motor

continues running. Switch off the device and remove the cause, then the device can

be switched on again.

– If the rotation brush of the small turbo brush H has been blocked, the rotation brush

stops rotating. The motor continues running. Switch off the device and remove the

cause, then the device can be switched on again.

MOPPING ADAPTER

Instruction for use:

1. Check whether switch K5 is set to "Off". If not, set the switch to this position.

2. Remove tank K2 from the mop adapter K (Fig. 11). Remove plug K4 and fill in clean

water (warm or cold). Plug the tank when filled.

3. Soak and wring out mop pad K7 before use.

4. Then assemble the mop adapter (Fig. 11).

5. Attach mop adapter to the device (Fig. 1).

6. Set switch K5 to „On" (water drop symbol) and switch the device to the required

suction power.

7. Clean the floor using slow forward and backward movements.

8. After cleaning, switch off the device and set switch K5 to "Off".

Notes

– The mop attachment can be used while vacuum cleaning is on or off. If you are

mopping and vacuuming at the same time, first move the vacuum cleaner forwards on

the surface you are cleaning and then return using the same path you have already

vacuumed and cleaned. This will ensure the proper sequence of the cleaning process

- vacuum cleaning to get rid of any dirt first, followed by floor mopping.

– Do not use/pour any detergent in the mop water tank.

VI. REMOVING DUST CONTAINER, FILTERS, WATER TANK

DUST CONTAINER REMOVAL (D)

When taking out the dust container D follow the procedure indicated in Fig. 3. Dispose

of dirt contained in the dust container with regular household waste. An emptied and

cleaned container is to be put back into the vacuum cleaner in reverse order.

INPUT HEPA FILTER REPLACEMENT (D4)

To remove the filter, follow the procedure indicated in Fig. 3. To fit a new filter

in the vacuum cleaner, proceed in reverse order.
