MaXiO System Manual
13
Input Gain Control
Controls the amount gain applied to the input signal from the XLR or TRS connector of specific
channel. Microphone signals can be amplified with 48dB maximum, line level signals with up to
30dB.
Analog Input Level Meter LEDs
The meters indicate the signal level for the analog inputs.
2.4.2 MIDI signal LEDs & Phantom power
MIDI signal LEDs.
Phantom Power Switch
+48V DC phantom power (for balanced condenser microphones) will be supplied via every
XLR input connector when this button is enabled. Note that this affects only those input
channels that are set to receive microphone signals (check ).
2.4.3 Analog Outputs
Headphone output with gain control
You can monitor the playback signal from output 1, 2 through the headphone output. The output
level can be adjusted with the volume pot.
Analog 2 XLR and 2 1/4” TRS outputs
5
8
14
2
7
6
4
6
7
8 14
