Display Bezel Mounting (continued)
6 Very carefully cut the hole in the mounting
surface.
7 Feed the display module cable through the
bezel and the opening in the dash then route it
to the interface.
8 Remove the masking tape protecting the trim
panel.
9 Clean the mounting surface thoroughly.
10 Apply the double-sided adhesive tape to the
display bezel.
11 Mount the Display Module using the bezel
adhesive.
12 Plug the connector into the Interface connector
labeled “Display Module.”
13 Secure and conceal the cable under trim
panels.
Control Module (Blue Shrink)
1 Determine the best location for the Control
Module. If installed by a professional, the
customer should be consulted. An optimal
location is easily visible and accessible from
the driver’s position, and does not interfere
with normal driving. Avoid locations that require
reaching through or around the steering wheel.
2 Clean the mounting surface thoroughly.
3 Mount the Control using the pre-applied
adhesive.
4 Route the cable to the Interface and plug into
the connector labeled “Control Module.”
5 Secure and conceal the cable under trim
panels.
Concealed Alert Indicator (Gray Shrink)
1 Determine the best location for the Alert
Indicator. If installed by a professional, the
customer should be consulted. An optimal
location is clearly visible from the driver’s
position and does not take a driver’s eyes o
the road for more than a moment.
2 Ensure there are no hidden cables, brackets,
or other components behind the mounting
location, and that there is adequate clearance
behind the panel.
3 Cover the mounting surface with masking tape
to prevent accidental scratches.
4 Carefully mark the location and drill a 1/4” hole
through the mounting panel.
5 Remove the masking tape protecting the trim
panel.
6 From the front side, snap one of the panel
bezels provided into the hole.
7 Snap the Alert Indicator into the panel bezel
from the back side.
8 Route the cable to the Interface and plug into
the connector labeled “Concealed Alert LED.”
9 Secure and conceal the cable under trim
panels.
20 21
Installation
Installation
Rear Radar Receiver* (Optional)
1
Follow the same installation instructions as for
the Front Radar Receiver but with the receiver’s
arrow oriented to point out the rear of the vehicle.
2 Entry points to the vehicle’s interior may be
available behind the license plate or lights.
Rear Laser Shifter VX Sensors* (Optional)
IMPORTANT! When using optional Rear Shifter
VX sensors* ensure DIP switches 3 and 4 are
moved down to the REAR SHIFTER position. See
the Interface illustration on page 13.
1 Follow the same installation instructions as for
the Front Laser Shifter VX Sensors but with the
sensors oriented to point out the rear of the
vehicle.
2 Entry points to the vehicle’s interior may be
available behind the license plate or lights.
* Included with ESCORT Redline Ci 360c
Radio Mute Cable
1 The radio mute cable (included) allows the
detector to be connected to compatible audio
systems with a “Radio Mute” wire or connector.
Once connected, the audio level of the stereo
is reduced automatically during an alert.
2 Please refer to your audio system’s manual for
proper connection to your audio system.
Operation Test
After all components are installed correctly:
1 Turn ESCORT
Redline Ci-c
on by turning on
the vehicle’s ignition and, if necessary, press
the power button on the Control Module.
2 ESCORT
Redline Ci-c
will cycle through a
startup sequence.
3 If any error messages come up, see the
Owner’s Manual troubleshooting section for
suggested solutions.
USB Update Cable
The USB Update cable allows updating the
ESCORT Redline
Ci-c
’s DEFENDER database
and rmware. Redline
Ci-c
’s red light and speed
camera DEFENDER database is easily updated
using our exclusive detector software tools found
on our web site. Firmware, or the operating
software for the detector, can also be updated
using these tools.
In order to have access to these updates, please
register your ESCORT
Redline Ci-c
at www.
escortradar.com. Once registered, you will receive
email notications when updates are available.
If you have any questions, please call or visit our
website. One of trained radar specialists will be
happy to assist you:
800.433.3487 or escortradar.com.
