7
Live wire alert
The device can detect AC cables at a 2" (51mm) depth when scanning in the stud or metal detection modes. When live AC voltage
is detected, the AC wiring alert icon (11) will appear on the screen.
AC scanning mode
Press the AC (AC mode) button to select the live wire detection mode. Complete the calibration and repeat the scanning
procedure as described above in the "Metal detection mode" section.
You can adjust the device sensitivity in this mode. Calibrating on the surface with previously detected AC cables reduces the
sensitivity and narrows the search area. After completing the calibration, repeat the scanning procedure as described above. You
can reduce the sensitivity of the device multiple times to narrow the search area even more and locate the live wire with greater
accuracy.
!
Live wire detection will not work beyond a depth of 2" (51mm) from the scanned surface. Conduits encased in concrete,
behind sheer plywood, metallic wall coverings will cause very limited detection and may not be detected at all.
Low battery indicator
If the low battery indicator (3) starts flashing, immediately change the battery.
Specifications
Max. detection depth live wire: 51mm (2")
non-ferrous metals: 60 mm (2½"), ferrous metals: 80 mm (3")
wood/metal studs: 13mm (½"), 25mm (1"), 38mm (1½")
Sound alert +
Light alert +
Operating temperature range 0… +40°C (operating), −10… +50°C (storage) /
+32… 104°F (operating), +14… 122°F (storage)
Power supply 2pcs AAA batteries
The manufacturer reserves the right to make changes to the product range and specifications without prior notice.
Care and maintenance
Do not exclusively rely on the detector to locate items behind scanned surfaces. Do not assume that there is no live cabling
inside a wall. Always use caution when nailing, cutting, or drilling in walls, floors, and ceilings that may contain live cabling.
Calibrate the device regularly. Do not try to disassemble the device on your own for any reason. For repairs and cleaning of any
kind, please contact your local specialized service center. Protect the device from sudden impact and excessive mechanical
force. Store the device in a dry cool place. Only use accessories and spare parts for this device that comply with the technical
specifications. Never attempt to operate a damaged device or a device with damaged electrical parts! If a part of the device or
battery is swallowed, seek medical attention immediately.
Battery safety instructions
Always purchase the correct size and grade of battery most suitable for the intended use. Always replace the whole set of
batteries at one time; taking care not to mix old and new ones, or batteries of different types. Clean the battery contacts and
also those of the device prior to battery installation. Make sure the batteries are installed correctly with regard to polarity
(+ and –). Remove batteries from equipment that is not to be used for an extended period of time. Remove used batteries
promptly. Never short-circuit batteries as this may lead to high temperatures, leakage, or explosion. Never heat batteries in
order to revive them. Do not disassemble batteries. Remember to switch off devices after use. Keep batteries out of the reach
of children, to avoid risk of ingestion, suffocation, or poisoning. Utilize used batteries as prescribed by your country’s laws.
