3/8” (10mm)
3
” (75mm)
Drill 6 pilot holes using a 3/8” (10mm)
diameter drill bit. Make sure the depth of
the pilot holes is not less than 3”
(75mm).
2B-1
2B-2
Wall Thickness
≥5 1/2” (140mm)
Position the Wall Plate Template [03] at
your desired height. Level the Wall Plate
Template [03] and mark the pilot hole
locations.
Electric Drill
(Not Included)
2B-3
Use the hammer to knock the Wall
Anchor [A2] into the wall. Be sure the
Wall Anchor [A2] are seated flush with
the concrete surface.
A2
Hammer
(Not Included)
Pencil
(Not Included)
Level
(Not Included)
02 03 04 05 06 07 08 09 10 11 12 13 14
03
