Equip® POS Thermal printer User Manual
47
characters are set
When barcode readable character (HRI) printing is set, the control character is
replaced with a space.
When CODE128 ( m = 73) is selected:
- Refer to Appendix A, CODE 128 for information and character sets.
- When using CODE 128, follow the instructions below to encode:
① The character set (one of CODE A, CODE B and CODE C) must be selected
before bar code data.
② Selection of the character set is accomplished by sending the character “{” in
combination with another character; the ASCII character “{” is sent by sending
successive characters.
“{” is accomplished by sending the character ‘{’ twice in succession.
Special characters Send data
ASCII code Hexadecimal code Decimal code
Special
characters
Sending data
ASCII code
Hexadecimal code
Decimal code
SHIFT
{S
7B,53
123，83
CODEA
{A
7B,41
123，65
CODEB
{B
7B,42
123，66
CODEC
{C
7B,43
123，67
FNC1
{1
7B,31
123，49
FNC2
{2
7B,32
123，50
FNC3
{3
7B,33
123，51
FNC4
{4
7B,34
123，52
“{”
{{
7B,7B
123，123
[Example] e.g. print “No. 123456”.
In this example, the printer first prints “No.” with CODE B, and then prints the
remaining digits with CODE C. The printer prints “No.” with CODE B, and then
prints the remaining digits with CODE C:
GS k 73 10 123 66 78 111 46 123 67 12 34 56
CODE 128:
1b 40 1d 48 02 1d 68 64 1d 77 03
1d 6b 49 0A 7B 42 4E 6F 2E 7B 43 0C 22 38
- If character set selection is not at the top of the bar code data, the printer stops
processing this command and treats the remaining
The printer will stop processing this command and treat the rest of the data as
normal data.
- If “{” and the character immediately following it are not the combination
specified above, the printer stops processing this command and treats the
