Equip® POS Thermal printer User Manual
34
Function
Description
Prints a raster bitmap, with the raster bitmap mode selected by the m value:
m
Mode
DPI(Vertical)
DPI(Horizontal)
0,48
Normal
200
200
1,49
Multiple Width
200
100
2,50
Multiple Height
100
200
3,51
Multiple Width,
Multiple Height
100
100
Parameter
range
0 ≤ m ≤ 3 or 48 ≤ m ≤ 51
0 ≤ xL ≤ 255
0 ≤ xH ≤ 255
0 ≤ yL ≤ 255
0 ≤ d ≤ 255
k = ( xL + xH * 256 ) * ( yL + yH * 256 ) ( k≠0 )
Default value
None
Supported
Models
All models
Precaution
xL, xH indicates the number of horizontal direction bitmap bytes (xL+xH*256)
yL, yH indicates the number of vertical direction bitmap points (yL+yH*256)
In standard mode, this command is valid only when there is no data in the printer
buffer.
The print modes such as character enlargement, bolding, double printing,
inverted printing, underlining, and black and white reversal are not valid for this
command.
The portion of the bitmap that exceeds the print area is not printed.
ESC is valid for raster bitmap.
During macro definition, this command stops the macro definition and executes
the command. This command is not included as part of the macro definition.
d represents the bitmap data. A 1 in the corresponding bit of each byte indicates
that the point is printed, and a 0 does not print the point.
Example of
use
When xL+xH*256=64
Horizontal position printing of line segments (Curve Print command)
Command
name
Horizontal position printing of line segments (Curve Print command)
Command
ASCII：GS ‘ n x1sL x1eH x1eL x1eH ...xnsL xnsH xneL xneH
Highest bit
Lowest bit
dots
dots
dots
