Equip® POS Thermal printer User Manual
33
name
Command
code
ASCII：FS p n m
Decimal system：28 112 n m
Hexadecimal system：1C 70 n m
Function
Description
Prints the NV bitmap in the mode specified by m n
m
Mode
0, 48
Normal
1, 49
Multiple Width
2, 50
Multiple Height
3, 51
Multiple Width, Multiple Height
Parameter
range
0 ≤ m ≤ 3
48 ≤ m ≤ 51
1 ≤ n ≤ 255
Default value
None
Supported
Models
All models
Precaution
n is the number of NV bitmaps (defined with the FS q command).
m specifies the bitmap mode.
An NV bitmap is a bitmap defined in nonvolatile memory. Defined with FS q
FS p Printing
This command is invalid when the specified NV bitmap does not exist.
In standard mode, this command is valid only when there is no data in the
print buffer.
This command is not affected by print modes (bold print, overlap, underline,
character size, highlight print, or character 90 ), except for inverted print
modes such as rotate.
If the downcast bitmap to be printed exceeds one line, the excess data is not
printed.
This command feeds n dots (n is the NV bitmap height) in Normal and
Multiple Width modes, and 2n dots in Multiple Height and Quadruple Size
modes (this command feeds 2n dots, and n is the NV bitmap height),
independent of the line spacing set by ESC 2 or ESC 3.
After prints the bitmap, the command sets the print position at the beginning of a
line and treats the subsequent data as normal data.
Example of
use
None
Printing raster bitmaps
Command
name
Printing raster bitmaps
Command
code
ASCII：GS v 0 m xL xH yL yH d1...dk
Decimal system：29 118 48 m xL xH yL yH d1...dk
Hexadecimal system：1D 76 30 m xL xH yL yH d1...dk
