EMU HARDWARE (70681)

Visit the ENTTEC website for the latest version.

..



USER MANUAL

4 |

ID: 5956415

Document Updated: March 2025

Hardware Feature

◼ Touring-grade hardware interface expertly designed for ENTTEC's EMU Software offering easy-to-

use sound-to-light integration.

◼ 3-pin/5-pin XLR provide a combined DMX output of 512 channels.

◼ EtherCON Ethernet RJ45 with DHCP server supporting ENTTEC lighting controllers for multi-

universe lighting output.

◼ ¼" TRS jack for footswitch/MIDI input to control lighting states in EMU Software.

◼ Type-C USB connection to PC for power and data transfer.

◼ Opto-isolation protects your computer from stray voltage or phantom power mistakenly

connected to the DMX line

◼ Convenient mounting holes for secure DIN Clip installation.

◼ Customisable aesthetic status LED.

◼ TS35 DIN mount (using provided DIN Clip accessory)

Physical Dimensions

Mounting Method

The EMU Hardware supports DIN rail mounting. To install, attach the DIN rail clip using the screws

provided in the product packaging. Once secured, mount the product onto a suitable TS35 rail for

installation.

Note: The mounting accessory have been designed to hold the

weight of the EMU HARDWARE only, excess force caused by

cable strain can cause damage.
