BrightEye 90-F

BrightEye 90-F - Page 11

HD/SD SDI/Cpst In

This BNC input accepts an analog composite video signal, an HD SDI serial

digital video signal, or an SD SDI serial digital video signal with or without

embedded audio. External AES audio can be inserted into the SDI input stream

or replace existing embedded audio.

Ref In

This BNC accepts an analog composite video signal or Tri-Level Sync signal

which is used as the genlock and timing reference for the internal Frame

Synchronizer. Typically the reference signal is Color Black or Color Bars fed from

a master sync generator (such as the BrightEye 55).

AES 1/2, AES 3/4, AES 5/6, AES 7/8

The AES 1/2, AES 3/4, AES 5/6, and AES 7/8 BNCs are either inputs or outputs

depending on how the unit is configured (Mux 8, Mux 4, or Demux). Each

connector inputs or outputs an AES stream (each stream containing 2 channels).

When the unit is configured as Mux 8, the AES BNCs are inputs. When configured as

Demux, the AES BNCs are outputs.When configured as Mux 4, two BNCs are

inputs and two BNCs are outputs.
