BrightEye 76 - Page 9

Setting Vid Gain to unity ensures correct analog output levels from an analog

input source that is at proper level itself. The Vid Gain indicator illuminates red

if the control is adjusted higher or lower than its nominal setting. To reset gain to

its nominal setting (green) press both arrows simultaneously.

Audio

Output level and the status of audio channels 1 and 2 are indicated by the state

the VU and Gain indicators:

This indicator illuminates red when the audio level exceeds the

headroom level set with the Peak Indicator control in BrightEye PC or

Mac. Additionally, the VU indicator illuminates yellow when the output is

above 0 VU, and illuminates green when the output is above -20 VU. When

the output level is below -20 VU, the indicator does not illuminate.

Gain

This indicator Illuminates green when output gain is set to its nominal or

unity value. It illuminates red when gain is set to other than unity.
