www.ensembledesigns.com
BrightEye 71 and 71-F - Page 12
HD/SD 8 Channel Analog Audio Embedder/Disembedder User Guide
TM
BrightEye 71 and 71-F
Audio Input Menu
The appearance of the Input menu will depend on the mode of the module and the type of audio
being used.
Multiplexer Mode
When the module is set for Mux, the Aud Input menu provides the controls shown below:
• Group A Status – the status of the audio selected in Group A Select will be displayed as
No Audio Present, Group 1 OK, Group 2 OK, Group 3 OK, or Group 4 OK.
• Group B Status – the status of the audio selected in Group B Select will be displayed as
No Audio Present, Group 1 OK, Group 2 OK, Group 3 OK, Group 4 OK or Off.
• Group A Select – select the audio group to multiplex from Group 1, Group 2, Group 3, or
Group 4.
• Group B Select – select the audio group to multiplex from Group 1, Group 2, Group 3,
Group 4, or Off.
