BrightEye 11-HD HD/SD SDI to Analog Converter

BrightEye-6

C, Pr, R Out

The function of this connector varies according to the selected output format as

follows:

• C – S-Video C output (use Y /C S-Video adapter) NTSC or PAL (SD only)

•Pr– SMPTE/Beta analog component color difference R-Y channel output

•R– RGB Red output

Y, Pb, B Out

The function of this connector varies according to the selected output format as

follows:

•Y– S-Video Y output (use Y /C S-Video adapter) NTSC or PAL (SD only)

•Pb– SMPTE/Beta analog component color difference B-Y channel output

•B– RGB Blue output

Cpst, Y, G Out

The function of this connector varies according to the selected output format as

follows:

• Cpst – NTSC or PAL composite output (SD only)

•Y– SMPTE/Beta analog component Y (luminance) output

• G – RGB G output
