16 Channel setting in the ETS
Remote Control Remo KNX RF • Version: 14.09.2021 • Technical changes and errors excepted.
6. Channel setting in the ETS
6.1. Transfer protocol
Abbreviations:
RRead
WWrite
C Communication
T Transfer
UUpdate
No Text Function Flags DPT type Size
1 System: Block settings
(0: block,1: unblock)
Input RWCT [1.3] DPT_Enable 1 Bit
2 System: Low battery Output R-CT [1.2] DPT_Bool 1 Bit
3 System: Battery charge [%] Output R-CT [5.4] DPT_Per-
cent_U8
1 Byte
Media page (Objects 10-32)
10 Media: On/off Output --CT [1.1] DPT_Switch 1 Bit
11 Media: Off Output --CT [1.1] DPT_Switch 1 Bit
12 Media: On/off feedback Input -WCT [1] 1.xxx 1 Bit
13 Media: Playback Output --CT [1.1] DPT_Switch 1 Bit
14 Media: Pause Output --CT [1.1] DPT_Switch 1 Bit
15 Media: Playback feedback Input -WCT [1.1] DPT_Switch 1 Bit
16 Media: Increase/decrease volume Output --CT [3] 3.xxx 4 Bit
17 Media: Volume [%]
Feedback
Input -WCT [5.4] DPT_Per-
cent_U8
1 Byte
18 Media: Volume [%] Output --CT [5.1] DPT_Scaling 1 Byte
19 Media: Next title Output --CT [1] 1.xxx 1 Bit
20 Media: Previous title Output --CT [1] 1.xxx 1 Bit
21 Media: Current title Input -WCT [16] 16.xxx 14 Bytes
22 Media: Current artist Input -WCT [16] 16.xxx 14 Bytes
23 Media: Current album Input -WCT [16] 16.xxx 14 Bytes
24 Media: Next playlist Output --CT [1] 1.xxx 1 Bit
25 Media: Previous playlist Output --CT [1] 1.xxx 1 Bit
26 Media: Current playlist Input -WCT [16] 16.xxx 14 Bytes
27 Media: Shuffle Output --CT [1.1] DPT_Switch 1 Bit
28 Media: Repeat Output --CT [1.1] DPT_Switch 1 Bit
29 Media: Mute Output --CT [1.1] DPT_Switch 1 Bit
30 Media: Shuffle feedback Input -WCT [1] 1.xxx 1 Bit
31 Media: Repeat feedback Input -WCT [1] 1.xxx 1 Bit
