22 Operation
Control System KNX WS1000 Style • Version: 28.05.2018 • Technical changes and errors excepted.
•No compression (RLE)
• The data must be saved in the uppermost level of the card's directory (root
directory)
The SD card is pushed into the slot, until it clicks into place.
The card will automatically be recognised. If image data are stored on the card, the
symbol for „play-back“ appears at the bottom right-hand side of the weather data dis-
play.
The image changes approx. every 45 seconds (for images with 24-bit color intensity).
To return to the weather data display, touch the screen or remove the SD card (briefly
press down on the card so that it pops out).
Further information about the image display can be found in chapter
6.2. Using an SD card
The SD card slot can be found on the
inner face of the housing.
The display is held on the wall by
magnets. It is connected to the power
electronics in the concealed box with
a cable. Lift the display unit to the
front without breaking the cable con-
nection.
Wall
Press „play-back“ to start the slideshow.
