45 Parameter setting
Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.
Temperature hysteresis: 1°C
Relative humidity hysteresis: 2% RH
Absolute humidity hysteresis: 2 g/kg
8.12. VOC parameter settings
Use Offsets to adjust the readings to be sent.
The unit can calculate a mixed value from its own reading and an external value. Set
the mixed value calculation if desired. If an external portion is used, all of the following
settings (threshold values, etc.) are related to the overall reading.
The maximum reading can be saved and sent to the bus. Using the "Reset VOC max-
imum value" objects, the value can be reset to the current reading. The value is not re-
tained after a reset.
8.13. VOC threshold values
Activate the required VOC threshold value. The menus for setting the threshold values
are displayed.
300 ppm ... 1000 ppm: fresh air
1000 ppm ... 2000 ppm: used air
1000 ppm = 0.1 %
Minimum relative humidity in %
(Standard 30%)
10 ... 43; 30
Maximum absolute humidity in 0.1 g/kg
(Standard 115 g/kg)
50 ... 200; 115
Offset in ppm -100…100; 0
Use external measured value No • Yes
Ext. Reading proportion of the total reading 5% • 10% • ... • 50% • ... • 100%
All of the following settings are referred to the total value.
Sending pattern for internal and total
measured value
• never
• periodically
• on change
• on change and periodically
At and above change of
(relative to the last measured value)
(if sent on change)
2% • 5% • ... • 50%
Send cycle (if sent periodically) 5 s • 10 s • ... • 2 h
Use maximum value No • Yes
Use threshold value 1/2/3/4 Yes • No
