21 Transfer protocol
Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.
208 Logic input 9 Input -WC- [1.2] DPT_Bool 1 Bit
209 Logic input 10 Input -WC- [1.2] DPT_Bool 1 Bit
210 Logic input 11 Input -WC- [1.2] DPT_Bool 1 Bit
211 Logic input 12 Input -WC- [1.2] DPT_Bool 1 Bit
212 Logic input 13 Input -WC- [1.2] DPT_Bool 1 Bit
213 Logic input 14 Input -WC- [1.2] DPT_Bool 1 Bit
214 Logic input 15 Input -WC- [1.2] DPT_Bool 1 Bit
215 Logic input 16 Input -WC- [1.2] DPT_Bool 1 Bit
220 Display contrast (1 = higher | 0 =
lower)
Input -WC- [1.1] DPT_Switch 1 Bit
221 Display lighting (1 = on | 0 = off) Input -WC- [1.1] DPT_Switch 1 Bit
222 Display lighting Brightness Input RWC
T
[5.1] DPT_Scaling 1 Byte
223 Display lighting Switch off delay Input RWC
T
[7.5] DPT_TimePeri-
odSec
2 Bytes
230 Date for display Input -WCT [11.1] DPT_Date 3 Bytes
231 Time for display Input -WCT [10.1] DPT_TimeOf-
Day
3 Bytes
232 8 bit object 1 for display Input -WC- [5] 5.xxx 1 Byte
233 8 bit object 2 for display Input -WC- [5] 5.xxx 1 Byte
234 8 bit object 3 for display Input -WC- [5] 5.xxx 1 Byte
235 16 bit object 1 for display Input -WC- [9] 9.xxx 2 Bytes
236 16 bit object 2 for display Input -WC- [9] 9.xxx 2 Bytes
237 Text message 1 for display Input -WC- [16.0]
DPT_String_ASCII
14
Bytes
238 Text message 2 for display Input -WC- [16.0]
DPT_String_ASCII
14
Bytes
239 Back jump release for display Input -WC- [1.1] DPT_Switch 1 Bit
240 Push button 1 long-term Output R-CT [1.8] DPT_UpDown 1 Bit
241 Push button 1 short-term Output R-CT [1.10] DPT_Start 1 Bit
242 Push button 1 switching Output R-CT [1.1] DPT_Switch 1 Bit
243 Push button 1 dimming Input /
Output
RWC
T
[3.7] DPT_Control_-
Dimming
4 Bit
244 Push button 1 encoder 8 bit Output R-CT [5] 5.xxx 1 Byte
245 Push button 1 encoder 16 bit Output R-CT [9] 9.xxx 2 Bytes
246 Push button 1 scene Output R-CT [5] 5.xxx 1 Byte
247 Push button 2 long-term Output R-CT [1.8] DPT_UpDown 1 Bit
248 Push button 2 short-term Output R-CT [1.10] DPT_Start 1 Bit
249 Push button 2 switching Output R-CT [1.1] DPT_Switch 1 Bit
250 Push button 2 dimming Input /
Output
RWC
T
[3.7] DPT_Control_-
Dimming
4 Bit
No Text Function Flags DPT type Size
