Je bekijkt pagina 21 van 68
19 Transfer protocol
Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.
130 VOC controller: Setpoint (1:+ | 0:-) 1 = Incre-
ment | 0 =
Decre-
ment
-WC- [1.2] DPT_Bool 1 Bit
131 VOC controller: Variable ventilation
(1st step)
Output R-CT [5.1] DPT_Scaling 1 Byte
132 VOC controller: Variable ventilation
(2nd step)
Output R-CT [5.1] DPT_Scaling 1 Byte
133 VOC controller: Ventilation status
(1=ON | 0=OFF)
Output R-CT [1.1] DPT_Switch 1 Bit
134 VOC controller: Ventilation status 2
(1=ON | 0=OFF)
Output R-CT [1.1] DPT_Switch 1 Bit
135 Actuating variable comparator 1:
Input 1
Input -WC- [5.1] DPT_Scaling 1 Byte
136 Actuating variable comparator 1:
Input 2
Input -WC- [5.1] DPT_Scaling 1 Byte
137 Actuating variable comparator 1:
Input 3
Input -WC- [5.1] DPT_Scaling 1 Byte
138 Actuating variable comparator 1:
Input 4
Input -WC- [5.1] DPT_Scaling 1 Byte
139 Actuating variable comparator 1:
Input 5
Input -WC- [5.1] DPT_Scaling 1 Byte
140 Actuating variable comparator 1:
Output
Output R-CT [5.1] DPT_Scaling 1 Byte
141 Actuating variable comparator 1:
Block
Output -WC- [1.2] DPT_Bool 1 Bit
142 Actuating variable comparator 2:
Input 1
Input -WC- [5.1] DPT_Scaling 1 Byte
143 Actuating variable comparator 2:
Input 2
Input -WC- [5.1] DPT_Scaling 1 Byte
144 Actuating variable comparator 2:
Input 3
Input -WC- [5.1] DPT_Scaling 1 Byte
145 Actuating variable comparator 2:
Input 4
Input -WC- [5.1] DPT_Scaling 1 Byte
146 Actuating variable comparator 2:
Input 5
Input -WC- [5.1] DPT_Scaling 1 Byte
147 Actuating variable comparator 2:
Output
Output R-CT [5.1] DPT_Scaling 1 Byte
148 Actuating variable comparator 2:
Block
Output -WC- [1.2] DPT_Bool 1 Bit
149 AND logic 1: 1 bit switching output Output R-CT [1.1] DPT_Switch 1 Bit
150 AND logic 1: 8 bit output A Output R-CT [5] 5.xxx 1 Byte
151 AND logic 1: 8 bit output B Output R-CT [5] 5.xxx 1 Byte
No Text Function Flags DPT type Size
